-Size requirement for the incinerators is 750-850 kg capacity
-The burn rate should be 80-100 kg/hour
-The primary chamber should have an operating temperature of 900-1200 degree C
-The incinerator should have a high temperature secondary chamber and 2 second gas retention time at 850-1150 degree C so that it is suitable for high risk materials
-The incinerator should have temperature monitoring and thermostat control for ease of operation and assurance of burn temperature to confirm correct operation
-The incinerator should be capable of burning any of the hazardous wastes listed in the subsequent section
-The incinerator should be capable of burning diesel oil and should include a large fuel tank (10-500 litres) and generator (3-40 kV) set that can be carried on the trailer with the incinerator so that the unit requires no external electrical power supply
-The incinerator should be trailer mounted so that it is a portable unit
Hazardous Waste to be Incinerated:
Hazardous solid chemical:
Different types of combustible solids, used textiles, grease and toner, cartridges, chemicals for water purification and photographic consumables and plastic material, empty plastic/metal cans that still contain remnant hazardous materials, oil absorbent.
Hazardous liquid chemical:
Mainly different types of Acid, Paint, varnish, Acetone, White Spirit Aromatic-less Solvents, Synthetic Liquid for Break Systems, Aircraft De-icing Liquid, Hydraulic and Compressor oil, Freon, used in some older refrigeration units, Insecticide liquid/spray, air refresh spray and other similar chemicals
Mainly diesel or gasoline contaminated by water or solvents
Used and/or Contaminated oil:
Used motor oils and/or mineral oils unfit for their originally intended use. Mainly motor and gearbox oil (approximately 80%) contaminated by a mixture of white spirit and acetone (approximately 5%), hydraulic liquid (approximately 5%)
Waste oils/water, leaches, hydrocarbons/water mixtures, emulsion and leachate.
Soil populated by oil, fuel or chemicals
Contaminated soil populated by chemicals that has to be recycled in landfill
Contaminated soil – treated and replaced on site.
Oil Contaminated solids:
Rags, Absorbents, cardboard, oil and fuel filters, air filters are not consider as hazardous materials
Waste electrical or electronic appliances or assemblies, including printed circuit boards, containing toxic material and/or heavy emitting low radiation.
Used battery cells:
Dry battery, UPS battery or other types, unsorted waste batteries/battery cells, containing materials that are hazardous
Used lead-acid batteries:
Waste lead acid batteries, drained/un-drained, and whole or crushed
Hazardous medical waste:
Clinical and related waste, arising from medical, nursing or similar practices and waste generated in clinics during the investigation or treatment of patients (bio hazards)
Expired drugs solid:
Waste pharmaceuticals, drugs and medicines, including sensitive medicines
Expired drugs liquid:
Waste liquid pharmaceuticals, different type liquid chemicals for treatment, medical grease and paraffin based expired medicines.
Expired and/or contaminated food:
Spoiled fresh food or unusable MRE’s (Meal Ready to Eat – dry food)
